Instruction manual
Alpha DO 2000
3. Assembly and Installation
3.1 Mounting the Unit
Wall mount version
Unit:
MM [INCH]
ap
p
ro
x.
14
[.
55
]
39 [1.54]
144 [5.67]
14
4
[5.
67
]
78 [3.07]
Pg13.5 (3 pcs.)
111.50 [4.39]
27.5 [1.08]
24 [.94]
57.8[2.28]
For Pg13.5 cable glands
Holes for wall
mounting (2X)
21.
5
[.85]
6 [.24]
66.
5
[2.
62]
80 [3.15]
90
[3
.5
4]
90 [3.54]
Holes for post
mounting (4X)
Red Plugs for wall
mounting holes
enclosure (2X)
175 [6.88]
175 [6.88]
138 [5.43]
138 [5.43]
Cut-out mounting plates for post mounting
84 [3.30] 29 [1.14]
1-22 [0.03 - 0.87]
Threaded rod for panel mounting
Max.80
Seal gasket
Environmental protection class: IP 66, NEMA 4X (housing)
9
