Instruction Manual
CyberScan pH1500
12
pH
View
pH
View
% SLOPE
BUFFER
select
pH
s e l e c t
STABLE
Data
Data
clear
BUFFER
P1.0
View pH electrode offset
-
Allows you to view pH electrode
offset in mV after 1-point
standardization.
P2.0
View pH electrode slope
- View the pH electrode slope in
% after 2-point standardization
is successfully done.
P3.0
pH buffer group
- Select from 3 different buffer
groups, each containing 5-6
buffers, for auto buffer
recognition.
P4.0
pH resolution
-
Select various pH resolution
either 0.1, 0.01 or 0.001.
P5.0
Temperature Unit
- Select unit of measure for
Temperature either in °C or °F.
P6.0
Stability Indicator
-Set the stability indicator to be
displayed on the screen.
P7.0
Baud Rate
- To set the baud rate
(bits of second) of the
communication protocol
interface.
P8.0
Parity Bit
- Set the parity bit of the
communication protocol
interface.
P9.0
Stop Bit
- Set the stop bit of the
communication protocol
interface.
P10.0
Print Data
- To print current displayed
data or data stored in the
meter’s memory to a
computer or printer via
Rs232.
P11.0
Clear Stored Data
- To clear all stored data sets
for new data to be stored.
P12.0
Clear Buffer Values
- To clear the standardized
buffer values.
P14.0
Clear mV offset
-Select to clear of retain mV
offset stored earlier.
P13.0
View mV offset
mV
View
clear
In the setup mode, there are 12 setup menus for you to change the
operating parameters to suit your individual preference as well as to
configure RS232 communication interface protocol for printing.
While you are in each parameter Measure mode, pressing setup key
allows you to access all 12 setup menus (P1.0 to P12.0) in the pH
mode and other setup menus for mV and Relative mV modes. Refer
to Overview of Setup Menus below.
Mode
Setup Menus Accessible
pH
P1.0 to P12.0
mV
P5.0 to P11.0
REL mV
P5.0 to P11.0, P13.0 & P14.0
)
If you do not wish to make a selection or change the
option, pressing std key at any point of time allows you
to abort the setup menu and return to the Measure
mode.
Overview of Setup menus
