SHIMPO DT-900 - Manual (Page 26)

23
Mode Displays
LOW BATT LOW BATT LOW BATT LOW BATT
1200.0 1200.0 1200.0 1200.0
Message
RPM
TachMod TachMod TachMod TachMode e e e
no input
Ext.Mode Ext.Mode Ext.Mode Ext.Mode
no input
Low Battery indicator
, needs recharging. Although the
Stroboscope will continue to flash it is recommended that you
charge the battery when this message appears. Approximately
2.5 hours of continuos use per charge
External Mode
, automatically look for an external source of
signal. If source is found, LED power indicator will light up
green otherwise it will be red, and the message “no input”
appears. Maximum 12,500 FPM, Minimum 15 FPM. If max
value is exceeded the strobe will stop flashing but the clock
source frequency will continue to be displayed.
Tachometer Mode
, automatically look for an external source
of signal. If source is found, LED power indicator will light
up green otherwise it will be red, and the message “no input”
appears. Maximum 99 rpm, and the minimum is 15 rpm.
