RESPTZ37-SERIES
38
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Image Device:
4.5mm (1/4 inch 960H Dual-Scan CCD )
Optical/Digital Zoom:
37X/12X
Resolution:
650 TVL
Focal Length:
f = 3.5 – 129.5 mm
Angle of View:
3.5 mm – 54.4° Horizontal
129.5 mm – 1.6° Horizontal
Aperture:
f/1.5 – f/4.1
Sensitivity:
Normal: 0.02 fc (0.2 lux)
Slow Shutter: 0.0003 fc (0.003 lux)
ICR On: 0.001 fc (0.01 lux)
ICR On and Slow shutter: 0.000001 fc (0.00001 lux)
ICR On (Day/Night):
Yes
Wide Dynamic Range (WDR):
Yes
Motion Detection (in Preset):
Yes
Image Stabilizer
Yes
Tilt Angle:
-10° - 190° (Digital Flip)
Image Flip:
Yes
Auto Calibration:
0.1° - 6°
Speed:
0.1
° to 380°/sec. (proportional to zoom); 380°/sec.
maximum (with CTRL key pressed); Preset Speed:
380
°/sec.
Panning Angle:
360° continuous rotation
Alarm
8 inputs (NC/NO), 4 TTL outputs
Auto Scan:
1 Auto Pan & 16 Auto Scans
Preset:
240 presets
Pattern:
8 patterns (recording up to 500 sec.)
Tour:
8 tours (42 functions per tour)
Maximum Speed:
380° /sec.
Area Titles:
16 titles with 12 characters each
Privacy Zones:
8 with two methods Block or Video Off
Control Protocol:
RS-485/422; Baud rate: 2400~38.4k bps (default: 9600
bps), REVOTRAX, Pelco-D, Pelco-P
ID (Camera Address):
1 - 255
Dimensions:
See Figure 3.
Certifications:
CE EMC, FCC Class A, CSA
Input Voltage:
18 to 30 VAC; 24 VAC, nominal
Current:
1 A ,nominal
