Revo RECBH36-2 - Manual

Weatherproof IR Bullet Camera
600TV Lines
Super High Resolution Color Camera
INSTRUCTION MANUAL
Unit: mm
Weight - Unit:
Shipping: 0.627 lb. (0.285 kg)
0.935 lb. (0.425 kg)
5
1
50
65.5
139.5
9 9
EXTERNAL DIMENSION
2 3
600TV Lines
Super High Resolution Color Camera
PRINTED IN KOREA
50302925A
SPECIFICATIONS
Power source
Power consumption
Image sensor
Total pixels
Scanning system
Scanning frequency
Sync. system
Resolution
Min. illumination
Video output
Power input
AGC
2:1 interlace
15.734KHz(H) x 59.94Hz(V)
Internal
600 TV lines (Color)
0.1 lux(COLOR), 0 lux(BW at IR ON) @ F1.2, 50 IRE
More than 50dB (AGC off)
f=3.6mm Fixed Lens
795(H) x 595(V)
DC Jack
(NTSC)
330mA(4.0 Watts) - IR LED ON
811(H) x 507(V)
MODEL
S/N ratio
White Balance
Power
15.625KHz(H) x 50Hz(V)
Lens
Connector
&
etc.
(PAL)
Video output
Operating Temperature
1.0 Vp-p (75 ohm, composite)
BNC Connector
] -10°C ~ +50°C [14°F ~ 122°F
General
Operating humidity 0 ~ 96% (non-condensing)
II 1/3" Sony Super HAD CCD
Day / Night
IR LED / SENSOR
LED Lighting Distance IR LED 24EA(850nm / 40 degree) , CDS 1EA
20M
Auto Exposure ON
AUTO (ATW)
DC 12V +/- 10%
Lens mount Fixed mount
Gamma 0.45
AUTO
AUTO
2D-DNR
Smart IR ON
ON
Function
Electronic shutter 1/60 ~ 1/100,000 sec. 1/50 ~ 1/100,000 sec.
BASE INSTALLATION
M3X20mm Tapping Screws
Caution
"Adjusting the position of the camera after installation could
potentially damage the cable"
Position camera for best field of view then tighten camera/mount
tension adjustment screws (x2)
Tension adjustment screw
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specifications are subject to change without notice.
* Use the power consumption 4W over.
