REVO America www.revoamerica.com RESPTZ37-SERIES
23
some lighting conditions, you may need to manually adjust the red and blue
settings for optimal viewing. When Automatic White Balance is enabled, the
camera measures the image and automatically adjusts the red and blue
settings to balance white. When automatic white balance is disabled, the
camera uses the values set for the red and blue gain to balance white.
WB SETUP
MODE : AUTO
R GAIN : ---
B GAIN : ---
SAVE AND EXIT(ESC TO CANCEL)
MODE: AUTO/INDOOR/OUTDOOR/AWB/MANUAL
AUTO: Wide range automatic white mode. Color range from 1700 to
11000 °K.
INDOOR: Indoor white balance mode. Optimized for indoor use.
OUTDOOR: Outdoor white balance mode. Optimized for outdoor use.
AWB: Automatically computes the white balance value output using
color information from the entire screen automatically. Color range from
2900 to 6500 °K.
MANUAL: Enables setting of RGAIN (Red) and BGAIN (Blue) manually
to obtain white balance.
RGAIN: Red Gain. Adjustable from 0-200.
BGAIN: Blue Gain. Adjustable from 0-200.
RGAIN / BGAIN modes are controllable only in MANUAL mode.
