Page 17
REVO America
www.revoamerica.com
RESPTZ37-SERIES
15
Installing the Camera
Refer to the following manuals to install your camera model.
Model
Manual
RESPTZ37-1 Indoor Flush-Mount Dome Camera
HCS251-HV
RESPTZ37-1HSC Outdoor Ceiling-Mount Dome Camera
RESPTZH-1
RESPTZ37-1HSW Outdoor Wall-Mount Dome Camera
Wiring
WARNING
Never work with power on. You should always disconnect electrical power prior to
installation or removal of any equipment.
A typical system configuration is shown in Figure 6. Figure 7 shows the wiring connections.
Figure 6. Typical System Configuration
