5.1 Single Run Graph
This template provides custom titles and a graph of the merged data.
The graph vertical axis is scaled to the range of the uploaded pressure
values and the horizontal axis is scaled to the number of samples
uploaded.
The template file name is:
BetaLOG-template-single-run-pressure-graph.xlt
The Export options corresponding to this template are as follows:
Field Include Field Insert Description Excel Cell
Run # or Label Yes No B3
Gauge Description Yes No B5
Log and Sample Type Yes No B10
Interval Time Yes No B12
Pressure Unit Yes No B8
Custom factor Yes Yes B18
Trip Setpoint and Reset Yes Yes B16
Initial Zero and Tare Yes Yes B14
Zero Changes Yes No J24
Temperature Readings No No any
Pressure Readings Yes No B24
5.2 Single Run Pressure and Temperature Graph
This template provides custom titles and a graph of the merged data.
The pressure graph vertical axis is scaled to the range of the uploaded
pressure values and the horizontal axis is scaled to the number of
samples uploaded. The temperature graph vertical axis is scaled to
the range of the uploaded temperature values and the horizontal axis is
scaled to the number of samples uploaded.
The template file name is:
BetaLOG-template-single-run-pressure-temperature-graph.xlt
The Export options corresponding to this template are as follows:
