Clearing Logged Data
Click the Clear button. After confirmation of the action, all logged data
is cleared from the gauge, the data logging mode is set to Enabled,
Demand, and all data on the display is refreshed.
Sending Setup Configuration
After making the desired selections, click the Send button. The
configuration is sent to the gauge and all data on the display is
refreshed. The data logging mode must be set to Enabled, Download
to change anything more than the mode.
Retrieving Setup Configuration
Click the Retrieve button. The gauge description, present capacity,
and present setup are retrieved from the gauge and displayed in the
appropriate fields.
Setup Configuration Fields
Data Logging
Disabled Disable data logging in the gauge. All data
logging functions are removed from the
gauge's CONFIG menu sequence.
Enabled, Download Enable data logging in the gauge with all
logging parameters downloaded from this
application. All data logging functions
associated with parameter changes are
removed from the gauge's CONFIG menu
sequence. The only gauge functions
available are starting and stopping data
logging, displaying the number of free
records, and clearing all logged data.
Enabled, Demand Enable data logging in the gauge with all
logging parameters set in the gauge. This
application may only be used to upload
logged data, clear all logged data, retrieve
data logging parameters, and change the
data logging mode. The data logging
functions available in the gauge's CONFIG
menu sequence are starting and stopping
data logging, displaying the number of free
records, changing the logging interval,
changing the samples per run, and clearing
all logged data. The log type is fixed at
Continuous and the sample type is fixed at
Interval End.
