Technical data

The responsibility as to the suitability, intended use and corrosion-resistanc

of the materials used in their construction rests solely with the purchaser.

4.1

Versions, full-scale ranges, accuracies

Versions

Primary head (S)

Signal converter (C)

GFM 700 K integral system

GFS 700 K

GFC 700 K

GFM 700 F remote system

GFS 700 F

GFC 700 F

GFM 700 F-EEx

GFS 700 F-EEx

GFC 700 F - EEx

(Ex versions (remote system))

Approval to ATEX (Ex II 2 G)

signal converter is installed

EEX de IIC T6 oder EEx d IIC T6

in non hazardous area

DEMKO Nr. 00ATEX2118 X

Full-scale ranges (configurable)

Q

100%

volume flow

v

100%

flow velocity

Standard

14 – 25000 m

3

/h

60 – 88000 US Gal/min

2 – 25 m/s
6.6 – 80 ft/s

Option

14 – 30000 m

3

/h

60 – 156000 US Gal/min

2 – 30 m/s
6.6 – 100 ft/s

Error limits

Accuracy

DN

≥ 80 / ≥ 3”

v < 2 m/s

± 0.04 m/s (± 0.13 ft/s)

v

≥ 2 m/s

± 2% of measured value

DN

≤ 65 / ≤ 1½”

± 2% of measured value + 0.04 m/s
(± 2% of measured value + 0.13 ft/s)

Repeatability

± 0.5% of measured value



4.2

GFS 700 Primary head

Diameter

DN 50 – 600 / 2” – 24” (option DN 700 – 1200 / 28” – 48”)

Flange connections

Pressure rating (standard)

to DIN 2501

DN 50, DN 80:

PN 40

40 bar / 580 psig

DN 65, DN 100 – 150:

PN 16

16 bar / 230 psig

DN 200 – 600:

PN 10

10 bar / 150 psig

to ANSI B 16.5

2” – 24”: Class 150 lb / RF

19 bar / 275 psig

Special versions

max. 100 bar / 900 lb

Max. operating data Gas-Temperature

Operating

pressure

Integral systems

standard option

Ambient temperature

40°C / ≤ 104°F

≤ 140°C / 284 °F

≤ 25 bar / 360 psig

≤ 40 bar / 580 psig

Ambient temperature

60°C / ≤ 140°F

≤ 60°C / 140 °F

≤ 25 bar / 360 psig

≤ 40 bar / 580 psig

Remote systems

≤ 180°C / 356 °F

≤ 25 bar / 360 psig

≤ 40 bar / 580 psig

Hazardous-duty versions

≤ 180°C / 356 °F

≤ 20 bar / 300 psig

Max. allowable flow velocity

≤ 25 m/s / ≤ 80 ft/s, optionally ≤ 30 m/s / ≤ 100 ft/s

Max. allowable meter size (DN)

DN

max

[mm] = 200 x

ρ

Gas

[kg/m

3

] or [inches] = 0.47 x

ρ

gas

[lb/ft3]

as a function of process product

D

ensity ρ

Gas

in kg/m

3

or in [lb/ft

3

]

Protection category (IEC 529 / EN 60529) IP 65 equivalent to NEMA 4 and 4X

Materials

Measuring tube and flanges

Standard

DN 50-300

2“-12“

SS 1.4301 (measuring tube) and steel (flanges)

DN

350-600

14“-24“

steel

Option

DN 50-600

2“-24“

SS 1.4404

DN 50-600

(only DIN)

SS 1.4571

Ultrasonic sensors SS

1.4301

Gaskets Viton
