KROHNE IFC 110 Converter EN - Manual

Installation and
operating instructions
IFC 110 F V2.0
IFC 110 F-EEx V2.0
Signal converters for
electromagnetic flowmeters
Applicable to
Software Versions
● Display & control unit
No. 3.19937.02.00
● A/D converter
No. 8.13393.02.00
● Outputs/inputs (I/O)
No. 3.16230.01.00
How to use these Instructions
Flowmeters are delivered ready for operation.
The flow sensor must be installed in the pipeline as described in the instructions for
installation inside the packing of the flow sensor.
– Connection of power supply (Sect. 1.1-1.2) Pages 4- 5
– Electrical connection between IFC 110 F and primary head (Sect. 1.3) Pages 6-13
– Electrical connection of outputs and inputs (Sect. 2) Pages 14-22
– Start-up (Sect. 3) Page s 23
Power the flowmeter. THAT’S ALL. The system is operative.
Operator control of the IFC 110 F signal converter is described in Sect. 4.
