Device description
2.1 Scope of delivery
The scope of delivery always consists of the transmitter and its documentation.
2.2 General description
TT 10 C TT 10 C TT 10 C TT 10 C
RTD RTD RTD RTD
The TT 10 C is an analogue 2-wire in-head transmitter for temperature measurements with
single resistance thermometers of the type Pt100. The TT 10 C provides a temperature linear 4-
20 mA output. The main field of application is industrial environments.
The transmitter is optionally available in an intrinsically safe version for installation in
potentially explosive areas. These devices are labelled with the "Ex" symbol and are approved for
use in zone 0.
Thermocouple Thermocouple Thermocouple Thermocouple
The TT 10 C T/C is an analogue 2-wire in-head transmitter for temperature measurements with
single thermocouple input of type J, L, T, K and N. It provides a mV linear 4-20 mA output. The
main field of application is industrial environments.
The TT10 C T/C is not available in an intrinsically safe version.
Installation on rail Installation on rail Installation on rail Installation on rail
All in-head versions are intended for installation in a "B connection head" or larger according to
DIN 43729. As an alternative you can also mount the in-head version on a rail according to EN
60715 TH35 with the help of the rail installation kit (further information on page 18). In this way
you may operate an in-head transmitter with an Ex approval with sensors in potentially explosive
areas, if the transmitter is installed in the safe area (though this case is very uncommon).
TT 10 R TT 10 R TT 10 R TT 10 R
RTD RTD RTD RTD
The TT 10 R is an analogue 2-wire rail-mount transmitter for temperature measurements. It has
the same features like the in-head version, except that a version with an Ex-approval does not
exist.
Thermocouple Thermocouple Thermocouple Thermocouple
The TT 10 R T/C is an analogue 2-wire rail-mount transmitter for temperature measurements. It
has the same features like the in-head version.
The rail-mount transmitter is intended for installation on a rail according to EN 60715 TH35.
The TT10 R T/C is not available in an intrinsically safe version.
