TABLE 4. GENERAL SPECIFICATIONS FOR TWO (2) HIGH POWER 1000W BOP UNITS
CONNECTED IN PARALLEL
SPECIFICATION RATING/DESCRIPTION CONDITION
INPUT CHARACTERISTICS
a-c voltage nominal 230 Va-c
Single phase
range 176 - 264 Va-c
Frequency nominal 50-60 Hz
>65 Hz, leakage
exceeds spec
range 47 - 65 Hz
Current 176 Va-c 19A maximum
264 Va-c 13A maximum
Power factor
Source 0.99 minimum
nominal output power
Sink 0.97 minimum
Efficiency 65% minimum
Switching frequency 80 KHz PFC Stage
EMC Compliance EN61326-1 (1997) Class A equipment
EMC immunity to: ESD EN61000-4-2 Electrostatic discharge
Radiated RF EN61000-4-3
EFT EN61000-4-4 Electrical fast transient/burst
Surges EN61000-4-5
Conducted RF EN61000-4-6
EMC emissions Conducted EN61000-3-2 harmonics
EN61000-3-3 fluctuation & flicker
Conducted EN55011/CISPR11 0.15 to 30 MHz
Radiated EN55011/CISPR11 30 to 1000 MHz
Leakage current 3.5 mA 230V a-c 47-63 Hz
Insulation coordination Input Installation Category II
Overvoltage Category II
Output Installation Category II
Overvoltage Category II
Pollution degree 2
OUTPUT CHARACTERISTICS
Type of stabilizer Voltage-current, 4-quadrant Switch mode
Switching frequency 100KHz Output Stage
Source adjustment
range voltage -100% to +100% of rating
0 to 50 deg C
current -100% to +100% of rating
Sink adjustment range voltage -100% to +100% of rating
Recuperated energy is sent back into
line for reuse current -100% to +100% of rating
Programming
resolution / accuracy
Voltage 14 bits / 0.2%
Current 14 bits / 0.5%
Limits 12 bits / 0.5% voltage or current
Readback
resolution / accuracy
Voltage 16 bits / 0.2% main or limit channel
Current 16 bits / 0.5% main or limit channel
Readback
rate/array measurement rate 1 ms (default) range: 0.25-25ms
measurement array 64 samples
