7. Verify the master unit is in STANDBY, then connect a short across the output of the parallel con-
figuration (see Figure 1 or Figure 2).
8. At the master unit calibrate the parallel combination as follows:
a. From the main screen, press % to enter the Settings Menu.
b. From the Settings menu, gain access to the Protected Settings menu by first entering the
password (see step 2c above).
c. Press @ from the Protected Settings menu to begin Calibration.
d. Press # from the main calibration menu to select Multiple. Monitor the LCD to see the sta-
tus while calibration of the parallel configuration proceeds automatically (this may take
approximately 3 minutes).
e. When the calibration is complete, the LCD will display
PLEASE REMOVE SHORT FROM OUT-
PUTS OF POWER SUPPLIES Depress Any Key to continue.
f. When prompted, enter the calibration date using U or ADJUST control to scroll through the
characters and T or R to select the character position, then press ENTER.
g. Exit the Calibration menu by pressing $ to save the settings upon power-up.
9. Remove the short across the output of the parallel configuration.
IV. SPECIFICATIONS
Table 3 lists the model parameters unique to a parallel combination of two 1000W BOP Power Supplies.
Table 4 lists the general specifications applicable all the parallel combinations listed in Table 3.
TABLE 3. MODEL PARAMETERS FOR TWO (2) HIGH POWER BOP 1000 WATT UNITS (PARALLEL)
Model
d-c Output Range Closed Loop Gain
E
O Max
I
O Max
Voltage
Channel
Current
Channel
TWO 1000 WATT MODELS
BOP 10-75MG ±10V d-c ±150A d-c 1.0 15.0
BOP 20-50MG ±20V d-c ±100A d-c 2.0 10.0
BOP 36-28MG ±36V d-c ±56A d-c 3.6 5.5
BOP 50-20MG ±50V d-c ±40A d-c 5.0 4.0
BOP 72-14MG ±72V d-c ±28A d-c 7.2 2.8
BOP 100-10MG ±100V d-c ±20A d-c 10.0 2.0
