OUTPUT CHARACTERISTICS (Continued)
Voltage stabilization in
voltage mode
source effect 0.05% of rating min-max input voltage
load effect 0.1% of rating 0-100% load current
time effect (drift) 0.05% of rating 0.5 through 24 hours
temperature 0.05%/deg C of rating 0 to 50 deg C
ripple and noise 2% E0max p-p Includes switching noise
Current stabilization in
current mode
source effect 0.05% of rating min-max input voltage
load effect 0.2% of rating 0-100% load voltage
temperature 0.05%/deg C of rating 0 to 50 deg C
ripple and noise 2% I0max p-p Includes switching noise
Error sensing 0.25V per wire Above rated output
Transient recovery in
voltage mode
maximum excursion 5% of nominal output nominal voltage, 50% load step
Recovery time 200
µ
sec Return within 0.1% of set voltage
Isolation voltage 300V Output to ground
Output limiting voltage and current limited in four quadrants
Output Stage Protection
Heatsink overtemperature,
switchers overcurrent for master
and slave units
Triggers latched shutdown protection of
entire master/slave combination
Input Stage Protection (PFC)
Overvoltage, undervoltage, overcurrent,
heat sink overtemperature, fan inopera-
tive for master and slave units
Triggers latched shutdown protection of
entire master/slave combination
Circuit breaker overcurrent
Trips circuit breaker to shut off unit
(master or slave)
PROGRAMMING/DISPLAY CHARACTERISTICS
Small signal Bandwidth voltage channel 2 KHz minimum into nominal resistive load, 10% of rating
current channel 400 Hz minimum Into short circuit, 10% of rating
Rise/Fall Time voltage channel 500/200
µ
sec
into nominal resistive load, 10-90%,
0 to ±100% of rating
current channel 1.5/2.5 msec
into short circuit, 10-90%,
0 to ±100% of rating
Analog control voltage channel –10V to +10V
Full range output,
10K Ohm input impedance
current channel –10V to +10V
Digital control local Panel-mounted keypad Direct Entry
remote IEEE 488-2 (GPIB)
SCPI
remote RS 232
remote RS 485 (BITBUS) IEEE 1118
Display front panel 4" backlit LCD displays all functions
remote All parameters read back on GPIB or RS 232 buses
TABLE 4. GENERAL SPECIFICATIONS FOR TWO (2) HIGH POWER 1000W BOP (CONTIN-
UED)UNITS CONNECTED IN PARALLEL
SPECIFICATION RATING/DESCRIPTION CONDITION
