KEPCO KIT 219-0445, Cables for two High Power BOPs User Manual
Cable, Kepco

©2003, KEPCO, INC
Data subject to change without notice
228-1472 REV 3
091903
I N S T R U C T I O N S H E E T
KEPCO
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
An ISO 9001 Company.
CABLE
219-0445
KIT
CABLE KIT NO. 219-0445
BOP 1000W MODELS (2) IN PARALLEL
I.
DESCRIPTION.
This kit contains the three cables, Power Output, Bitbus and Master/Slave Control, required to operate
two 1000 Watt BOP High Power models in parallel, effectively doubling the output current capacity.
Only two identical models may be configured to operate in parallel. Table 1 lists the equipment supplies
in this Kit.
This manual is arranged as follows:
•
Section I lists the equipment supplied.
•
Section II explains how to install the cables and configure the two units to operate in parallel,
including initial calibration.
•
Section III describes how to calibrate a previously installed parallel configuration.
•
Section IV lists the specifications for the parallel combination.
•
Section V provides special operating instructions for the parallel combination.
II.
INSTALLATION.
BE SURE ALL POWER IS DISCONNECTED FROM
POWER SUPPLIES BEFORE INSTALLING CABLES
TABLE 1. EQUIPMENT SUPPLIED
Item
Purpose
Kepco Part Number
Power Output Cable
Connects the power output terminals of the slave unit (OUT
and COMMON) to the corresponding power output terminals
of the master.
118-1112
Master/Slave
Control Cable
Connects the slave control ports of the master and slave for
parallel operation.
118-1107
Bitbus Cable
Allows communication between Master and Slave via Bitbus
118-1108
Instruction Manual
Provides installation and operation instructions for operating
two 1000W BOP models in Parallel
228-1472
WARNING
Document Outline
- I. DESCRIPTION.
- TABLE 1. Equipment Supplied
- II. INSTALLATION.
- FIGURE 1. Interconnections for Parallel Operation of Two (2) BOP High Power Models using Local Se...
- FIGURE 2. Interconnections for Parallel Operation of Two (2) BOP High Power Models using Remote S...
- FIGURE 3. Master Power Up Screen
- FIGURE 4. Power On Default Screen for Master Unit
- FIGURE 5. Power On Default Screen for Slave Unit
- TABLE 2. Slave Status Message Definitions (Displayed on Master Power Up Screen)
- FIGURE 6. Calibration Screen
- III. CALIBRATING AN EXISTING PARALLEL CONFIGURATION
- IV. SPECIFICATIONS
- TABLE 3. Model Parameters for two (2) High Power Bop 1000 Watt Units (Parallel)
- TABLE 4. General Specifications for two (2) High Power 1000W BOP units Connected in Parallel
- V. OTHER CONSIDERATIONS
- FIGURE 7. Power Up Status and Test Screen
