1). (mo, Rear view – KEPCO BOP 1KW-MG Quick Start Guide User Manual
Page 15
112113
228-1692 REV 3
15
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11355 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
FIGURE 1. BOP 1KW OUTLINE DIMENSIONS (SHEET 2 OF 2)
SLIDES TRAVEL DISTANCE: 23.000 [584.2]
22.000 [558.79]
SEE NOTE 6.
REAR VIEW
REMOVE FEET FOR
RACK MOUNTING.
