Specifications, Logic analyzer, Pecifications – GW Instek GDS-2000A series Quick start guide for Logic analyzer option User Manual
Page 18
S
PECIFICATIONS
Logic Analyzer
Sample Rate
500MSa/s
Bandwidth
200MHz
Record Length
2M max /ch
Input Channels
16 Digital (D15 - D0) or
8 Digital (D7~D0)
Trigger type
Edge, Pattern, Pulse Width,
Serial bus (I2C, SPI, UART)
Thresholds
Quad-D0~D3, D4~D7 . . .
Thresholds
Threshold selections
TTL, CMOS, ECL, PECL, User
Defined
User-defined Threshold
Range
±10V
Maximum Input Voltage
±40V
Minimum Voltage
Swing
±500mV
Vertical Resolution
1 bit
