Display Overview
Menu bar
B
u
s
/s
ig
n
a
l
lis
t
Tooltip
Data capture status
Tool bar
Horizontal
measurement bar
Trigger list
Menu bar
File operations.
Bus/Signal configuration.
Trigger configuration.
Data capturing.
Data operation and display setup.
Display setup, Shortcut setup, I2C
analysis, RS-232C analysis.
Display configuration and
organization of multiply files.
Help file and system information.
