S
PECIFICATIONS
The specifications apply under the following conditions:
GLA is powered on for at least 30 minutes, within
+20°C~+30°C.
General Specifications
GLA-1016 GLA-1032 GLA-1132
Channels 16 32 32
Memory
Total/Per
Channel 4Mbits/
256kbits 4Mbits/
128kbits 32Mbits/
1Mbits
Interface USB 2.0(1.1)
Operating
system Windows XP/ Windows 7/ Windows
Vista
Bandwidth 100MHz
Current
consumption Static: Maximum 200mA
Working: Maximum 400mA
Power
Dissipation Static: Max 1W
Working: Max 4W
Power Interface: USB
Working voltage: 4.5V~5.5V
Temperature Operating: 0˚C~50˚C
Storage: -40˚C~80˚C
Clock
GLA-1016 GLA-1032 GLA-1132
Internal 100MHz ~
200MHz,
asynchronous
100MHz ~
200MHz,
asynchronous
100MHz ~
200MHz,
asynchronous
External 0.001Hz ~
100MHz,
synchronous
0.001Hz ~
100MHz,
synchronous
0.001Hz ~
100MHz,
synchronous
