G
ETTING STARTED
The Getting started chapter introduces the GLA main
features, panel overview, display overview, installation
and power up.
Main Features
Model name Description
GLA-1016 16 channels, 256Kbit/channel
GLA-1032 32 channels, 128Kbit/channel
GLA-1132 32 channels, 1Mbit/channel
Characteristics • 100MHz full bandwidth
• Internal clock range: 100Hz ~
200MHz
• External clock range: 0.001Hz ~
100MHz
• Rich trigger functionalities:
voltage level, count, page,
position, delay time and clock,
edge and level configuration
• Memory utilization: max. x255
ratio data compression
• Signal characteristic filtering:
Enable function
• Various signal display mode:
waveform, listing, time,
frequency, and address
• I2C, RS-232C waveform analyzer
• Waveform statistics function
• Compact, lightweight profile
• PC operation with GUI
