Chapter 2 Operation
67
2.9. Converting the image data
This section describes how the VG's image data is set. BMP data or JPG data can be
converted into VBM data for use by the VG, VBM data can be sent to the VG and registered
on the memory card, VBM data from the VG can be received, and this data can be saved as
VBM files.
2.9.1. Startup method
Click the [Image] button of "VGBase" to start up the "Image Converter."
2.9.2. Window screen and description
No.
Item name
Details
No
The number of the image data registered in the VG appears here.
Name
The name of the image data displayed appears here.
Image display window
The image data is displayed here.
Image type
The displayed data image type is shown here.
Image size
The displayed data size is shown here.
Number of image colors
The number of colors of the displayed data is shown here.
