OPT PTN FAT error 2C Error in user-generated optional pattern FAT.
OPT PTN Not Registed 2D No user-generated optional patterns have been registered.
BMP data No error 2E Error in the image data number.
BMP data FAT error 2F Error in image data FAT.
BMP data Not Registed 30 The image data has not been registered.
Cur-DEV Incorrect 31 Illegal current data device (memory card or EEPROM).
Key Not Available 32 The function cannot be used because the key lock function is activated.
CURSOR Not Selected 33 The cursor pattern has not been selected.
OPT-0E(DDC) Disabled 34 The DDC optional pattern is invalid.
Flash ROM write error 35 A flash ROM write error has occurred.
GRAY data error 38 Error in the gray scale pattern data.
OPT-PTN data error 39 Error in the optional pattern data.
HALFTONE data error 3A Error in the half-tone pattern data.
CURSOR data error 3B Error in cursor pattern data.
PrgName data error 3C Error in the program name data.
GCOLOR data error 3D Error in the graphic color data.
ACTION data error 3E Error in the action data.
Vtotal over 40 Vtotal in the vertical timing data is outside the specified range.
Vdisp over 41 Vdisp in the vertical timing data is outside the specified range.
Vsync over 42 Vsync in the vertical timing data is outside the specified range.
Vbp over 43 Vbackp in the vertical timing data is outside the specified range.
Vfp over 44 The front porch in the vertical timing data is outside the specified range.
(Vtotal
≥ Vsync + Vbackp + Vdisp)
Vblank over 45 The blanking period in the vertical timing data is outside the specified
range.
Vfreq over 46 The vertical frequency in the vertical timing data is outside the specified
range.
VD over 47 VDstart + VDline in the vertical timing data is outside the specified
range. (Vtotal
≥ VDstart + VDline)
EQPfp over 48 EQPfp in the vertical timing data is outside the specified range.
EQPbp over 49 EQPbp in the vertical timing data is outside the specified range.
V-TIM data NG 4A Error other than those described above in the vertical timing data.
DDC1 Timeout 4B A timeout has occurred in DDC1.
DDC1 ACK error 4C An ACK error has occurred in DDC1.
DDC2 ACK error 4E An ACK error has occurred in DDC2.
The following errors may occur when user-generated optional patterns are executed.
Error message Code
(HEX)
Description of error
OPT-Prog. not Exist 81 The user-generated optional pattern does not exist.
Variables Stack Err 82 Variable stack error.
Register Stack Err 83 Register stack error.
Call Stack Error 84 Function stack error.
Illegal Instruction 85 Illegal instruction code.
Divide by Zero 86 An attempt was made to divide a number by zero.
Math Error 87 An error has occurred in a floating decimal point calculation.
