Model X40
Model X40 Instruction Manual Rev. 0.0 Page 11 of 23
address 7Fh is reached or until it is terminated by swiping the ENTER marker which will save the serial
sensors found up to that point and proceed to search for available RL4 modules starting with Modbus™
address 80h. The search will continue until Modbus™ address 87h is reached or until it is terminated by
swiping the ENTER marker which will save the RL4 modules found up to that point and proceed to search
for available AO4 modules starting with Modbus™ address A1h. (AO4 Modules will not be attached to
these units and this setup can be skipped if desired.) The search will continue until Modbus™ address A8h
is reached or until it is terminated by swiping the ENTER marker. The search will continue for available
CXT sensor transceivers and RXT-320 Transceivers starting with Modbus™ address 01h. The search will
continue until Modbus™ address 8Fh is reached or until it is terminated by swiping the ENTER marker
which will save the CXT sensor transceivers and RXT-320 Transceivers found up to that point.
To Abort Auto Configure, swipe of the PROG marker at any time while in search mode and the unit will
cancel the search and restore the default settings. Any devices found up during Auto Configure will not be
saved.
4.3.2 Set # of Channels, AO-4s, RL-4s (Alarm Stations)
The SET # OF CHANNELS/AO4S/RL4S/ALARM STATIONS menu allows the user to set the number of
active channels (1-32), the number of AO-4 modules (0-8) and the number of RL-4 modules and alarm
stations (0-4) each for Bank1 and Bank2. The number of active channels should match the number of
sensors being connected to the controller. AO4’s are not used with the CXT controller, and the AO4 value
should be set to ‘0’. Upon entering this menu, the LCD will display:
NOTE: It is possible to include RL-4 modules in the CXT configuration, but these modules
must be remotely mounted with their own transceiver for network identification.
SET # OF CHANNELS/AO4S/RL4S:
CHANNELS:## AO4S:#
RL4 MODULES/ALARM STATIONS
BANK1:# BANK2:#
These values can be changed by swiping the magnet over the markers of the up or down arrows to move
the arrow prompt “→” to the desired function. A swipe over the ENTER marker will select the function
indicated by the arrow prompt “→” and the value can be changed by swiping over the markers of the up or
down arrows. Another swipe over the ENTER marker will save the selected value.
NOTE: The number of activated channels can be less than (but not greater than) the
controller’s maximum input capacity (32 sensors).
4.3.3 Set # of CXT sensors and RXT-320s
The SET # OF RXT-320S menu is used to automatically search for all available CXT sensors and RXT-
320 transceivers in the network. Upon entering this menu, the LCD will display:
SETUP RXT-320S:
RXT 320S IN NETWORK:##
[CONFIGURE]
Swipe the ENTER marker to initiate the search. The CXT controller will perform an incremental search
for available CXT sensors and RXT-320’s starting with Modbus™ address 1 (decimal). The search will
continue until Modbus™ address 143 is reached, or until the search is terminated by swiping the ENTER
marker which will save the CXT sensors and RXT-320’s found up to that point.
