Model X40
Model X40 Instruction Manual Rev. 0.0 Page 10 of 23
MAIN DISPLAY
NORMAL OPERATION
MAIN MENU
SET # OF CHANNELS/AO4S/
RL4S/ALARM STATIONS
MAIN MENU
SET # OF RXT-320S
MAIN MENU
SET RF SILENCE
AND RF SLEEP
MAIN MENU
SET COMM BAUD RATES
MAIN MENU
SETUP CHANNEL DATA
MAIN MENU
SET CHANNEL ALARMS
MAIN MENU
SET MODBUS TIMEOUTS
RXT 320S: ##
CHANNELS: ##
AO4S: #
BANK 1: #
BANK 2: #
RF SILENCE: ON/OFF
RF SLEEP: ##:##
RF SLEEP: ON/OFF
COMM1 BAUD RATE: ####
COMM2 BAUD RATE: ####
RESPONSE TIMEOUT: ####
INTERPOLL DELAY: ####
SLAVE ID: ## in hex
DEVICE TYPE: XXXXXX
ANALOG INPUT: #
DECIMAL POINT: #
RANGE: #####
TYPE: XXXXXXXXX
RL4 BANK: XXX
ALM1 LEVEL: ##
ALM1 ASCENDING: Y/N
ALM2 LEVEL: ##
ALM2 ASCENDING: Y/N
ALM3 LEVEL: ##
ALM3 ASCENDING: Y/N
MAIN MENU
FLASHING BLUE LED CODES
MAIN MENU
SET MODBUS ADDRESS
MAIN MENU
SET RELAY FUNCTION
MAIN MENU
INHIBIT & ALARM TEST MODE
MAIN MENU
RF LINK QUALITY AND
BATTERY STATUS
MAIN MENU
SYSTEM DIAGNOSTICS
MAIN MENU
DISPLAY SETTINGS
MODBUS ADDRESS: ###
Sensor Comm Errors
Sensor Faults
AO4 Comm Errors
RL4 Comm Errors
RXT-320 Comm Errors
RXT-320 Battery Fault
RXT-320 Low Battery Alarm
Inhibit Test Mode Status
LATCHING (Bank1): Y/N
ENERGIZED (Bank1): Y/N
SILENCEABLE (Bank1): Y/N
LATCHING (Bank2): Y/N
ENERGIZED (Bank2): Y/N
SILENCEABLE (Bank2): Y/N
INHIBIT MODE: #:##
INHIBIT MODE: START/STOP
ALARM TEST MODE: ON/OFF
BRIGHTNESS: ###
BACKLIGHT TIMEOUT: #:##
CONTRAST: ###
Multiple Channels
Multiple Channels
Multiple Relays
(Fault, Alm1, Alm2, Alm3)
Multiple Transceivers
LCD DISPLAY TEST
LED DRIVER TEST
EXT RESET SWITCH TEST
RELAY DRIVER TEST
MODBUS DRIVER TEST
RF LINK: ###%
BATTERY: ##D ##H ##M
MAIN MENU
AUTO CONFIGURE SYSTEM
CHANNELS: ##
AO4S: #
RXT-320S:##
RL4/ALM BANK 1: #
RL4/ALM BANK 2: #
MAIN MENU
TIME AND DATE
TIME: HH:MM:SS
DATE: MM/DD/YY
MAIN MENU
VIEW TWA & PEAK
DATE,TIME,CHANNEL,
TWA:######,PEAK: ######
MAIN MENU
SET LOW BATTERY ALARMS
TTE(DD:HH:MM): ##:##:##
SOC(%): ###%
Figure 10 Menu Flow Chart
4.3.1 Auto Configure System
The AUTO CONFIGURE SYSTEM menu is used to automatically configure the CXT controller when
other Detcon devices have been installed as part of the control system. When this feature is activated, the
controller will search for Detcon CXT sensors, RL-4 modules, AO4 modules and RXT-320 transceivers by
polling the Network for these particular device types. Upon entering this menu, the LCD will display:
CONFIGURATION SUMMARY
CHANNELS:## AO4S:## RXT-320S:##
RL4/ALM ST BANK1:## RL4/ALM ST BANK2:##
[RUN SYSTEM AUTO CONFIGURE]
Swipe the ENTER marker to initiate the search. The CXT controller will perform an incremental search
for available sensors starting with Modbus™ address 01h. The search will continue until Modbus™
