LLC-BA Batch Unit
Operation and Programming Manual
7

Depth = 132mm/5.2 inches; depth w/ flange = 139mm/5.5 inches
Lexan® is a registered trademark of SABIC Innovative Plastics.
Weight

12 0z. (approx. 360 grams) without power supply
Environment

Storage: -40 to 85 deg. C

Operating: 0 to 50 deg. C (standard)

Humidity: 10-90% non-condensing
Power Supply

Supplied: 110VAC wall plug unit -16VAC/1000mA output w/6ft. cable to standard 2.1mm I.D. x
5.5mm O.D. female plug

Allowable supply range: 12-16VAC/300mA or 15-24VDC/300mA

Frequency Input: voltage triggered, 2.00 volt min. input level, 0 - 4KHz, 10KOhm imp.

Supply Output: (to sensor) approx. 20mA at approx. 15VDC

Relay Outputs: 2 Form C relay outputs (see table below for contact rating information)
Relay Contact Ratings
Maximum
Switched
Power Resistive Load
DC: 60W
AC: 125VA
Inductive Load
DC: 30W
AC: 60VA
Maximum Switched Voltage 220V DC, 250V AC
Maximum Switched Current 2A
Rated
Load Resistive Load
DC: 30V, 2A
AC: 110V, 0.5A
Inductive Load
DC: 30V, 1A
AC: 110V, 0.3A
