LLC-BA Batch Unit
Operation and Programming Manual
26
To program a batch quantity, press the BATCH key (SEL). The display momentarily reads SET BATCH-->1
and then displays BATCH1-> 0000000. Pressing SEL again increments the batch number. With a batch
selected, press and hold UP or DN to increase or decrease the batch quantity. To increase or decrease
rate, while holding the UP or DN, press and hold the SEL for medium rate or ENT for maximum rate.
Always release SEL or ENT before releasing UP or DN, or the LLC-BA will proceed to the next variable
leaving the last variable with an unpredictable value.
When the desired value displays, press ENT to store and advance to the next variable. This also activates
the batch number and the LLC-BA unit will return to the Display Mode. To program another Batch
quantity, repeat the above procedure. The BATCH key (SEL) and ENT key can be used for batch
selection/activation when in the PROGRAM mode. When programming is complete, the PROGRAM/RUN
input must be closed (TERM 4 connected to TERM 2) to enter the RUN mode and execute any activated
batch.
This ends the batch programming procedure. The LLC-BA will display the currently selected mode. To
initiate batch operation, set the RUN/PROGRAM key switch to the horizontal RUN position to enter the
RUN mode.
