LLC-BA Batch Unit
Operation and Programming Manual
5
Quick Start Guide
As with any precision-engineered device, always operate the LLC-BA Batch Unit in accordance with the
manufacturer’s instructions.
Connect to Flow Transmitter
You will connect three wires from the sensor to the back of the LLC-BA:

a red wire (electrical power)

a white wire (signal), and

a black wire (ground)
Color of wires may vary.
Insert the end of the red wire into upper connection #1 and use a screwdriver to secure. Insert the end
of the black into upper connection #2 and the end of the white wire into upper connection #3. Use a
screwdriver to secure.
Relays-to-Solenoid Connections
In a two-valve system, connect the 110VAC power wire from the optional high flow valve to upper
connection #5, neutral to #7; and connect power wire from low flow valve to upper connection #8 and
neutral to upper connection #10.
Other Connections
Other connections may be required, depending on your system. These include connections for remote
input/output devices, PLCs, and computers. See Input and Output Wiring Connections on page 9.
Connect Unit to Power
Insert the female end of the 110VAC adaptor into the AC 16V input at the back of the LLC-BA. Plug the
adaptor into a wall receptacle.
Basic Key Definitions and Key Strokes
The LLC-BA has four keys for data input and programming:

DN (down)

UP (up)

SEL (select)

ENT (enter)
Caution
Notice
