TOTALIZER 1 (TO1)
In TOTALIZER 1 mode, the LLC-BA displays the total of the currently programmed BATCH in progress.
Totalizer 1 resets to zero on a START input when in RUN mode and counts up to the batch amount. The
LLC-BA retains this total with power removed. The display is based on the programmed KFT value, KFT
engineering units, and decimal point.
TO1 000000.0 GAL
TOTALIZER 2 (TO2)
In TOTALIZER 2 display mode, the LLC-BA displays the current total accumulating in Totalizer 2 (Grand
Totalizer). Totalizer 2 accounts for all totalized flow; the user can only reset this value in the PROGRAM
mode. The LLC-BA retains this total with the power removed. Display is based on the programmed KFT
value, KFT engineering units and decimal point.
TO2 000000.0 GAL
BATCH Status
Indicates the state of the currently selected batch and whether the batch is RUNNING, PAUSED, or
DONE. It does not indicate actual batch progress.
BATCH 1 DONE
TO1 (REVERSE TOTAL 1)
Displays batch quantity when START input is closed and counts downward to zero at batch completion in
the reverse function of Totalizer 1. Display is reset with Totalizer 1. The LLC-BA retains this total with the
power removed. Display is based on KFT value, KFT engineering units, and decimal point.
TO1- 00000.00 GAL
Operations/Reset of Totalizers
The LLC-BA has two independent totalizers

TO1 (Totalizer 1) is the dedicated batch totalizer

TO2 (Grand Totalizer) keeps a running total of all flow
TO1 and TO2 rollover at 9999900 regardless of where the decimal is located. With power removed, the
LLC-BA retains totals.
Retained totals may not reflect the exact totalizer or batch value at the instant the power is removed
because these variables only update once every 15 seconds.
