RT-30EX Flow Transmitter
Operation and Programming Manual
33
RT-30EX User Manual, Rev. 1.7 02/07/2012
> Fine adjustment
Coarse adjustment
ON/OFF adjustment
Enter frequency value
to output
Output = 0500.00 Hz SEL
ENT
Fine limit output adjustment
When choosing the Fine adjustment option, the screen will appear which shows the active frequency
output value on the Limit 1, Limit 2 and Frequency outputs. Change this number to any desired value
between 2Hz and 4,500Hz and when
ENT button is pressed, the RT-30EX will output this value on the 3
outputs at the same time. This also returns the screen to the adjustment type screen. Press SEL to see
output value again and make new change.
Coarse limit output adjustment
When choosing the Coarse adjustment option, the screen will appear where the frequency output value
can be changed. When pressing the
UP button, the screen value (and Hz output value) increments by
25Hz to a max of 4,500Hz. When pressing the DN button, the screen value (and Hz output value)
decrements by 25Hz to a min of 2Hz. Press the EXIT button to leave this mode.
ON/OFF Limit output adjustment
When choosing the ON/OFF adjustment option, the screen will appear showing the current state of each
output pin. By pressing the
UP , DN and SEL buttons, each associated output as shown in Figure 45
above will change the state.
Use UP/DN keys to
change output in
25 Hz increments
Output = 0500.00 Hz
Fine adjustment
> Coarse adjustment
ON/OFF adjustment
SEL
ENT
Fine adjustment
Coarse adjustment
> ON/OFF adjustment UP > LIMIT 1 = OFF
DN > LIMIT 2 = OFF
SEL > FREQUENCY = OFF SEL
EXIT
Figure 43: Fine Limit adjustment screens
Figure 44: Coarse Limit adjustment screens
Figure 45: ON/OFF Limit adjustment screens
