RT-30EX Flow Transmitter
Operation and Programming Manual
14
RT-30EX User Manual, Rev. 1.7 02/07/2012
RT-30
S/N 0000000
Software Version 1.1.3
HART SW version 1.1.0
TOTAL
00249.00
GAL
LOGO screen
The LOGO screen shows 3 or 4 lines of important data for the display unit which is needed if contacting
the factory for support issues.
1. Line 1 shows the basic model name
2. Line 2 shows the unique serial number of the unit.
3. Line 3 shows the firmware version of the unit
4. Line 4 shows the firmware version of the HART protocol. NOTE: Line 4 will only show if the unit
was purchased with the HART protocol option
RATE screen
The RATE screen displays the flow rate in the programmed engineering units. If the linearizer is active,
‘LN’ shows in lower left corner. If the Gate Time filter is active, ‘GT’ shows in lower right corner.
TOTAL screen
The TOTAL screen displays the flow total in programmed engineering units. Pressing the RESET button
resets the value back to zero (0). The Total can also be reset remotely by connecting a momentary
voltage to the external RESET pin.
RATE
00100.00
GPM
LN GT
Figure 10: Logo screen
Figure 11: RATE screen
Figure 12: TOTAL screen
