Ordering Information
Pressure Unit
H= Inches H
2
O P= PSI
Wetted Material
1= 316L 4= Hastelloy (consult factory on availability)
Outputs
3= 1-5V
4= 4-20mA (2 wire loop powered)
6= 1-6V
Electrical
I= DIN 43650A
L= Conduit fitting, Cable 2 ft. (0.6 m)
M= Conduit fitting, Cable 4 ft. (1.2 m)
N= Conduit fitting, Cable 6 ft. (1.8 m)
P= Conduit fitting, Cable 10 ft. (3.0 m)
4 = Mini-Fast (CSA Only)
Series Type
Pressure Measurement
Insert 5-digit pressure code
Options
000= No Options
AST43LP A 00005 P 4 1 000 L -SS
Approval
(Left Blank)= UL ANSI/ISA 12.12.01 Class I Div 2 Non-Incendive Groups A, B, C, D (formerly UL1604)
-SS= Add “-SS” for CSA213 Class I Div 2 Non-Incendive Groups A, B, C, D and ANSI/ISA 12.27.01 Single Seal Approval
Pressure Ranges
PSIG Measurement
0-1
Pressure Code
00001
0-2.5 + 00069
0-5 00005
0-7.5 + 00208
0-10 00010
0-15 00015
+ 2.5 and 7.5 PSI Sensor must be ordered in inches of H
2
O.
Note: CSA approved products require case/earth ground electrical connection.
See wiring installation sheet for further details
Process Connection
A= 1/4” NPT Male
C= 1/4” BSPP Male
I= 1/4” NPT Female
P= 1/2” MNPT
T= G1/2 Male with Flush
Diaphragm (see options)
