TM
www.astsensors.com
© 2014 American Sensor Technologies Inc. AST45PT 03/13/2014.
All specifications subject to change without notice.
Pressure Ranges
Ordering Information
Wetted Material
1= 316L / 304 / Hytrel (cable) / Kynar (cord grip)
Electrical
N= Conduit fitting,
Cable 6 ft.
P= Conduit fitting,
Cable 10 ft.
X= Optional Length
(see options)
Outputs
3= 1-5V
4= 4-20mA
Pressure Unit
H= Inches H
2
O
P= PSI
Pressure Range
Insert 5-digit pressure code
Configuration Interface
L= Cone (removable)
Series Type
Temperature Output Range
1= -40 to 85°C (-40 to 185°F)
2= -40 to 125°C (-40 to 257°F)
3= 0 to 70°C (32 to 158°F)
4= -55 to 125°C (-67 to 250°F)
5= -18 to 93°C (0-200°F)
Fail Condition
N= Not Specified
H= Fail High
L= Fail Low
Options Cable Lengths:
140= 15 ft. (4.6 m)
075= 20 ft. (6.1 m)
074= 25 ft. (7.6 m)
004= 35 ft. (10.7 m)
130= 40 ft. (12.2 m)
065= 50 ft. (15.2 m)
003= 100 ft. (30.5 m)
050= 150 ft. (45.7 m)
AST45PT
L
00005
4
N
P
065
X
1
1
AST45PT
Gauge PSIG
Pressure Code
Feet of Water Column @ 4ºC (approx.)
0-100
00100
230.67
0-50
00050
115.33
0-30
00030
69.20
0-20
00020
46.13
0-15
00015
34.60
0-10
00010
23.07
0-7.5*
00208*
17.30
0-5
00005
11.53
0-2.5*
00069*
5.77
0-1
00001
2.31
*2.5 and 7.5 PSI Sensor must be ordered in inches of H
2
O.
(for wiring information visit: http://www.astsensors.com/wiring.php)
