PSIG Measurement
-14.7 to 25 ++
Pressure Code
V0025 ++
BARG Measurement
-1 to 2 ++
Pressure Code
V0002 ++
0-25 00025 0-2 00002
0-50 00050 0-5 00005
0-100 00100 0-7 00007
0-150 00150 0-10 00010
0-200 00200 0-20 00020
0-250 00250 0-35 00035
0-500 00500 0-50 00050
0-1,000 01000 0-100 00100
0-2,500 02500 0-250 00250
0-5,000 05000 0-350 00350
0-7,500 07500 0-500 00500
0-10,000 10000 0-700 00700
0-15,000 15000 0-1,000 01000
0-20,000 20000 0-1,400 01400
0-30,000 30000 0-2,000 02000
0-45,000 45000 0-3,000 03000
Pressure Ranges +
+ All pressures between 0-25 PSI and 0-45,000 PSI available. ++ Compound pressures up to -14.7 to 500 PSI available. Please consult factory.
Ordering Information*
Process Connection
A = 1/4” NPT Male
B = 1/8” NPT Male**
C = 1/4” BSPP Male
E = 9/16”-18 UNF Male [SAE6]
F = 7/16”-20 UNF Male [SAE4]**
P= 1/2” NPT Male***
W= F250C Female Autoclave****
Pressure Unit
B= Bar K= kg/cm 2 P= PSI
Wetted Material
0=17-4PH 1=316 L (available up to 10,000 PSI) 2= Inconel 718 (consult factory on availability)
Outputs
1= 0.5-4.5V ratiometric
2= 0-5V(3 wire)
3= 1-5V
4= 4-20mA
5= 0-10V(3 wire)
G= 1-10V
Electrical
A= 2 ft.(0.6m)
B= 4 ft.(1.2m)
C= 6 ft.(1.8m)
D= 10 ft.(3.0m)
E= Mini DIN 43650C
I= DIN 43650A
R= 6- Pin Bendix
Y= M12x1
Series Type
Pressure Range
Insert 5-digit pressure code
Options (contact factory for additional options)
000= No Options
AST20HA A 05000 P 4 0 000 E
(for wiring information visit: http://www.astsensors.com/wiring.php)
** Not available under 50PSI (1/8” NPT Male not available in 316L)
*** Pressures up to 15,000 PSI
****Pressures from 10,000 to 45,000 PSI, not available in 316L
H
Fail Condition
N= Not Specified H= Fail High L= Fail Low
*Minimum order quantities may apply to certain configurations, please contact factory for more information.
