* “B” and “F” not available under 50PSI (“B” not available in 316L)
+ All pressures between 0-25 PSI and 0-10,000 PSI available. **Compound pressures up to -14.7 to 500 PSI available. Please consult factory.
PSIG Measurement
-14.7 to 25**
Pressure Code
V0025**
BARG Measurement
-1 to 2**
Pressure Code
V0002**
0-25 00025 0-2 00002
0-50 00050 0-5 00005
0-100 00100 0-7 00007
0-150 00150 0-10 00010
0-200 00200 0-20 00020
0-250 00250 0-35 00035
0-500 00500 0-50 00050
0-1,000 01000 0-100 00100
0-2,500 02500 0-250 00250
0-5,000 05000 0-350 00350
0-7,500 07500 0-500 00500
0-10,000 10000 0-700 00700
Pressure Ranges +
Ordering Information
1 000
Process Connection*
A= 1/4” NPT Male
B= 1/8” NPT Male
C= 1/4” BSPP Male
F= 7/16” - 20 UNF Male
Pressure Unit
B= Bar K= kg/cm 2 P= PSI
Wetted Material
0= 17-4PH 1= 316L
Outputs
2= 0-5V (3-Wire)
5= 0-10V (3-Wire)
H= 1-6kHz
K= 0-5V (4-Wire)
L= 0-10V (4-Wire)
Electrical
A= 2 ft. (0.6m)
B= 4 ft. (1.2m)
C= 6 ft. (1.8m)
D= 10 ft. (3.0m)
E= Mini DIN 43650C
I= DIN 43650A
R= Bendix 6 Pin
Series Type
Pressure Range
Insert 5-digit pressure code
Options (contact factory for additional options)
000= No Options
A 00100 P 5 A AST4700
(for wiring information visit: http://www.astsensors.com/wiring.php)
* “B” and “F” not available under 50PSI (“B” not available in 316L)
