Alliance Laundry Systems UW35PV - Manual (Page 27)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
25 F232084
Grout Placement
Figure 13
PHM574N
PHM575N
PHM576N
10.88 in.
(276 mm)
PHM192N
UW100PV
20.69 in.
(526 mm)
43.81 in.
(1113 mm)
UW150PV
50 in.
(1270 mm)
56 in.
(1422 mm)
33 in.
(838 mm)
PHM574N
UW35PV
PHM575N
UW60PV
PHM576N UW80PV
30.12 in.
(765 mm)
17.88 in.
(454 mm)
36 in.
(914 mm)
35.63 in.
(905 mm)
11.94 in.
(303 mm)
35.94 in.
(913 mm)
12 in.
(305 mm)
27.5 in.
(699 mm)
4.06 in. typical
(103 mm)
41.12 in.
(1044 mm)
43.75 in.
(1111 mm)
14 in.
(356 mm)
17.5 in.
(445 mm)
33 in.
(838 mm)
4.06 in. typical
(103 mm)
20 in.
(508 mm)
4.06 in. typical
(103 mm)
41.12 in.
(1044 mm)
4.06 in. typical
(103 mm)
4.06 in. typical
(103 mm)
4.06 in. typical
(103 mm)
4.06 in. typical
(103 mm)
8 in. typical
(203.2 mm)
PHM605N
34 in.
(863.6 mm)
