Specifications and Dimensions
17 F232084
Floor Load Data
Static and dynamic loads on the floor or foundation are
shown in Table 2. Refer to Table 2 when designing
floors and foundations.
UWPV Pocket Hardmount Floor Load Data
Specifications
Design
Series
35 60 80 100 125 150
Static floor load, lbs (kN) U1-U5 1271 (5.64) 1677 (7.45) 2506 (11.2) 2741 (12.2) 3571 (15.9)
3936 (17.5)
U6 and
greater 1272 (5.66) 1677 (7.45) 2292 (10.2) 2490 (11.1) 3283 (14.6)
Static pressure, lbs/ft
2
(kN/m
2
)
U1-U5 169 (8.08) 188 (9.00) 200 (9.6) 219 (10.5) 223 (10.7)
202 (9.7)
U6 and
greater 169 (8.08) 187 (8.94) 184 (8.79) 199 (9.6) 205 (9.8)
Dynamic floor load, lbs (kN) U1-U5 1647 (7.3) 2824 (12.6) 3683 (16.38) 3681 (16.37) 5016 (22.31)
4358 (19.4)
U6 and
greater 1648 (7.33) 2824 (12.6) 3679 (16.36) 3690 (16.41) 5011 (22.29)
Dynamic pressure, lbs/ft
2
(kN/m
2
)
U1-U5 219 (10.5) 317 (15.2) 295 (14.2) 294 (14.1) 313 (15.1)
224 (11)
U6 and
greater 219 (10.5) 317 (15.2) 295 (14.2) 295 (14.2) 312 (15)
Dynamic load frequency, Hz U1-U5 13.3 12 11.2 10 9.7
11.7
U6 and
greater 15 13.6 12.8 12.8 9.7
1
Maximum vertical load,
lbs (kN)
U1-U5 2712 (12.0) 4184 (18.6) 5493 (24.43) 5551 (24.69) 7561 (33.63)
7508 (33.4)
U6 and
greater 2719 (12.1) 4168 (18.5) 5482 (24.38) 5561 (24.73) 7559 (33.62)
2
Minimum vertical load,
lbs (kN)
U1-U5 582 (2.59) 1464 (6.50) 1873 (8.3) 1811 (8.1) 2471 (11)
1208 (5.4)
U6 and
greater 576 (2.56) 1450 (6.45) 1852 (8.24) 1794 (8.0) 2434 (10.8)
Base moment, lb/ft (kN/m) U1-U5 4250 (5.35) 8894 (11.2) 11853 (16.1) 11849 (16.1) 16702 (22.7)
16707 (22.7)
U6 and
greater 4249 (5.8) 8895 (12.1) 11951 (16.2) 11984 (16.3) 16606 (22.5)
1 Acting in the downward direction against the floor.
2 Acting in the upward direction away from the floor.
Table 2
