Specifications and Dimensions
F232084 20
Mounting Bolt Hole Locations
Figure 8
PHM630N
PHM630N
( )
26.12 in.
(664 mm)
30.12 in.
(765 mm)
0.75 in.
(19 mm)
2 in.
(51 mm)
36
i
n
.
(914
m
m
)
34.
5 i
n
.
(8
76 mm
)
28.63 in.
(727 mm)
30.
19 in.
(767 mm
)
34.16 in.
(868 mm)
40.19 in.
(1022 mm)
43.28 in.
(1089 mm)
21.
19 in.
(538 mm
)
2 in.
(51 mm)
UW35PV
FRONT OF MACHINE
