Specifications and Dimensions
F232084 16
Figure 5
* Measurement of existing floor.
PHM720N
35 60 80 100 125 150
1
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
2*
6 in. (152 mm)
minimum
6 in. (152 mm)
minimum
6 in. (152 mm)
minimum
6 in. (152 mm)
minimum
6 in. (152 mm)
minimum
6 in. (152 mm)
minimum
3
9 in.
(229 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
12 in.
(305 mm)
4
36 in.
(914 mm)
36 in.
(914 mm)
43.75 in.
(1111 mm)
43.75 in.
(1111 mm)
48 in.
(1219 mm)
47.9 in.
(1217 mm)
5
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
0 - 8 in.
(0 - 203 mm)
max.
6
30.21 in.
(765 mm)
35.62 in.
(905 mm)
41.12 in.
(1044 mm)
41.12 in.
(1044 mm)
48 in.
(1219 mm)
47 in.
(1194 mm)
1
2 3
4 6
LENGTH FOR ONE
MACHINE
COMPACTED FILL DIRT18 in. (457 mm) DEPTH
3
3 3
5
Brush with
Cement
Grout
Brush with
Cement
Grout
Brush with
Cement
Grout
COMPACTED FILL DIRT 18 in. (457 mm) DEPTH
