32
M
ODEL
FT7000 XP U
SER
M
ANUAL
7. Refer to the paper insertion guide located in Figure 4-3. Pass the end of the paper roll over the
tension roller and insert into the take-up slot. The printer will automatically grab the paper.
Figure 4-7. Insert end of paper into slot.
Paper passes over the tension roller.
8. F
ROM
R
EAR
S
ERVICE
P
ANEL
- Enter M
ANAGEMENT
F
UNCTIONS
main menu. Select D
IAGNOSTICS
>
P
RINTER
. Choose option <3>, R
ESET
. The printer will reset and display a status report. Select
RINT
>. The report will print to the receipt printer. The printer is now in the Ready state.
9. Push printer tray back into the cabinet. Ensure the locking pin engages.
*IMPORTANT*
Only qualified service personnel are authorized
to repair or service the terminal. Should a mal-
function occur, DO NOT attempt to service the
unit yourself! Contact your Triton certified ser-
vice provider!
