3. Move the pusher plate against the notes with just enough pressure to hold the notes in the correct
position.
2. Align the notes and load them in the cassette. Level the note pile. Compress the note pile slightly by
hand. Single notes must not protrude from the bundle.
Figure 3-9. Align/level note pile. Figure 3-10. Move pressure plate against notes.
4. Fold the cassette lid down to its locked position. Insert the cassette back into the mechanism. Ensure
the cassette is pushed all the way back in the cassette channel.
Figure 3-11. Insert cassette back fully
into dispenser.
* I
MPORTANT
*
B
EFORE INSERTING CASSETTES IN THE FEED CHAN
-
NELS
,
ENSURE THE
O
PEN
/C
LOSE TAB
(
LOCATED IN
EACH CHANNEL
)
IS IN THE
“C
LOSE
”
POSITION
. T
HE
TAB SHOULD BE IN THE POSITION SHOWN BELOW
. I
F
NOT
,
BILL FEED ERRORS WILL OCCUR
!
Figure 3-12. Open / Closed tabs.
