Refer to Section 8, Error Recovery, for additional information about error codes.
T
HE
S
TATUS
F
UNCTION
The STATUS function allows you to obtain information on the operational status of three func-
tional areas of the dispensing mechanism:
• Feed Channels 1 - 4. Returns status of components associated with the Note Cassettes
and their associated feed channel components. Each Feed Channel can be tested
individually.
• Reject Channel. Returns the status of components associated with the Reject
Cassette, Bundle Output, Bundle Carriage and Note Diverter assemblies.
• Transport Channel. Returns the status of components associated with the Note
Qualifier assembly.
Use the diagrams on the following pages to interpret Return Code strings for these areas.
