7
Firmware Upgrades
Equipment
Description &
Basic Functions
Front View
From left to right:
Bluetooth Antenna. A coaxial female connector (reverse SMA
type) allowing you to connect a Bluetooth antenna for
wireless communication with a field terminal or other device.
Cellular Antenna. A coaxial female connector (SMA type)
allowing you to connect a cellular antenna. A cellular antenna
is required when the ProFlex 800 sends or receives RTK or
differential corrections data via its internal cellular modem
(GSM).
Take care not to swap the Bluetooth antenna and the cellular
antenna. The picture below shows where the shorter and
longer antennas should be connected.
Item Part Number
GLONASS 680500
GALILEO 680655
GPS L5 680656
Unlimited RTK 680502
Fast Output 680527
Flying RTK 680635
Embedded NTRIP caster 680636
GSM 680528
