Seed Hawk Manual Tool Bar Page 17
3.2 TIRE PRESSURE
Use the following chart to check and adjust, if necessary, tire pressure.
Tire Size Description PSI Rating
480 x 400 x 8 Packer Tire 20 PSI
11 L 15 Wing Tire (Front and Rear) 36 PSI
12.5 L 15 Main Frame Castor Tire (Front) 44 PSI
19.0 / 45 x 17 Front Main Frame Castor 58 PSI
500 / 45 x 22.5 Rear Axle Tire 52 PSI
30.5 L 32 SAT (Single) Rear Axle Tire 26 PSI
30.5 L 32 SAT (Inner
Dual) Rear Axle Tire 26 PSI
30.5 L 32 SAT (Outer
Dual) Rear Axle Tire 16 PSI
NOTE: Proper inflation of tire pressure contributes to longer tire life and proper
flotation for field operations. Tire inflation pressures listed are recommended
initial settings. Some soil conditions and operating environments may dictate
deviation (on Packer Tires Only) from the recommended settings. Contact
Seed Hawk
®
for additional information and advice if needed.
NOTE: If you do change your tire pressure, ensure that your opener is correctly placing your seed
at the depth you require.
3.3 TRACTOR REQUIREMENTS
Tractor Hydraulic Circuit Requirements
Circuit #1
Shank Lift/Lower (intermittent)
<40’ (12.2 m) Flow Rate
2-3 gal-US/min
40’+ (12.2 m)
Flow Rate 3-4 gal-US/min
Circuit #2
Hydraulic Manifold (continuous)
Model: SH Tool Bar
Flow Rate 3-4 gal-US/min (11.3-18.9 L/min)
Rear Steering (option) 3 gal-US/min (11.3 L/min)
SBR Hitch 2-3 gal-US/min
Low Pressure Tank Line(s) Tractor Reservoir 3-5 gal-US/min (11.3-18.9
L/min)
IMPORTANT! The low pressure return must
enter tractor reservoir directly.
