Dual port option drawing – SANDPIPER S05 Non-Metallic User Manual
Page 26
520-211-000
2/01
Model S05 Non-Metallic Design Level 1 Page 24
Dual Port Option Drawing
Illustration for Single Port Suction
with Dual Port Discharge
Illustration for Dual Port Suction and
Single or Dual Port Discharge
½" NPT or ½" BSPT
Connection
1" NPT or 1" BSPT External
½" NPT or ½" BSPT Internal
Connection
37
38
½" NPT or ½" BSPT
Connection
½" NPT or ½" BSPT
Connection
1" NPT or 1" BSPT External
½" NPT or ½" BSPT Internal
Connection
