User Manual of 5 Inch Network Speed Dome 58
Center, Send Email, Trigger Alarm Output, etc.
For example, when an external alarm is triggered, the network speed dome sends a
notification to an e-mail address.
6.6.1 Configuring Motion Detection
Purpose:
Motion detection is a feature which can trigger alarm actions and actions of
recording videos when the motion occurred in the surveillance scene.
Steps:
1. Set the Motion Detection Area.
Steps:
(1) Enter the motion detection settings interface
Configuration > Advanced Configuration> Events > Motion Detection
(2) Check the checkbox of Enable Motion Detection.
Figure 6-40 Enable Motion Detection
(3) Click . Click and drag the mouse on the live video image to draw
a motion detection area.
Note: You can draw up to 8 motion detection areas on the same image.
(4) Click to finish drawing.
Note: You can click to clear all of the areas.
