User Manual of 5 Inch Network Speed Dome
42
captured pictures.
Steps:
1. Enter the FTP Settings interface:
Configuration >Advanced Configuration > Network > FTP
Figure 6-20 FTP Settings
2. Configure the FTP settings, including server address, port, user name, password,
directory and upload type.
Setting the directory in FTP server for saving files:
In the Directory Structure field, you can select the root directory, parent
directory and child directory.
Root directory: The files will be saved in the root of FTP server.
Parent directory: The files will be saved in a folder in FTP server. The
name of folder can be defined as shown in following Figure 6-21.
Figure 6-21 Parent Directory
Child directory: It is a sub-folder which can be created in the parent
directory. The files will be saved in a sub-folder in FTP server. The name of
folder can be defined as shown in following Figure 6-22.
Figure 6-22 Child Directory
Upload type: To enable uploading the captured picture to the FTP server.
3. Click
to save the settings.
Note:
If you want to upload the captured pictures to FTP server, you also have to
