DVR User Manual
34
4.5.5 Alarm out
Alarm out includes three sub menus: alarm out, schedule and buzzer
①
Alarm out
Step 1: enter into system configurationalarm out; refer to Fig 4-28:
Step 2: in this interface, user can set relay alarm out
name and select hold time which means the interval
time between the two adjacent alarms.
Step 3: user can setup all channels with same
parameters.
②
Schedule
Step 1: enter into system configurationschedule;
Step 2: the setup steps of alarm out schedule are
familiar with schedule; user can refer to 4.4.1 Schedule
for details.
Fig 4-28 system configuration-alarm out
Note: the default schedule of motion detection is full-selected, that is, the color of schedule setting interface is blue.
③
Buzzer
Step1: enter into system configurationbuzzer;
Step2: tick off Buzzer and set buzzer alarm hold time
4.6 Network configuration
Network configuration includes four submenus: network, sub stream, Email and other settings.
4.6.1 Network
Step 1: enter into system configurationnetwork configurationnetwork; refer to Fig4-29:
Step 2: HTTP port: the default value is 80. If the value changed, user needs to add the port number when typing IP address in
IE address blank .i.e. set HTTP port to 82, IP addres
into IE browser.
