1A
Roof
G3926-3
1
X X X
1B
Door Bumper
T14882-1
12
X X X
1C Thread Forming Screw (Cutting) (Not Shown)
S9225-68
16
X X X
2A
Case Side - Right
G3510
1
X X X
2B
Thread Forming Screw (Cutting)
S9225-68
3
X X X
3A
Engine Top Cover Assembly
G3927
1
X X X
3B
Door Bumper
T14882
2
X X X
3C Latch
S24694
1
X X X
3D Rivet
T12584-9
2
X X X
3E
Rivet (Not Shown)
T12584-6
2
X X X
5
Fuel Warning Decal
T13086-26
1
X X X
6
Warning Label
M16197
1
X X X
7
Engine Service Decal
S25522
1
X X X
8
Warning Decal
T13086-62
3
X X X
9
Wiring Diagram
G4571
1
X • •
9
Wiring Diagram
G4571-1
1
• X •
9
Wiring Diagram
G4571-2
1
• • X
10
Logo Decal
S11893-4
2
X X X
11A Hinge Assembly
S24295-1
2
X X X
11B Rivet (Not Shown)
T12584-9
4
X X X
12A Hinge Assembly
S24295-2
2
X X X
12B Rivet (Not Shown)
T12584-9
2
X X X
13
Fan Shroud
G4245
1
X X X
14A Radiator
G3115-1
1
X X X
14B Thread Forming Screw
S9225-26
4
X X X
14C Plain Washer
S9262-121
4
X X X
14D Lock Washer
E106A-14
4
X X X
14E Thread Forming Screw
S9225-68
6
X X X
15
Radiator Cap
S9970-2
1
X X X
16
Drain Cock
T9956
1
X X X
17A Case Back
G4243
1
X X X
17B Thread Forming Screw
S9225-68
8
X X X
17C Fastener Button
T14659-1
4
X X X
18A Fan Guard (Right)
G4058-1
1
X X X
18B Thread Forming Screw
S9225-68
4
X X X
19A Fan Guard (Left)
G4060-1
1
X X X
19B Thread Forming Screw
S9225-68
4
X X X
19C Speed Nut
T11525-5
2
X X X
19D Thread Forming Screw
S9225-66
2
X X X
20
Over Flow Hose (Radiator to Coolant Bottle)
T10642-236
1
X X X
21
Hose Clamp (Over Flow Hose)
T13777-5
2
X X X
22A Lower Radiator Hose
L11881
1
X X X
22B Hose Clamp
S10888-16
4
X X X
22C Upper Radiator Hose
M20064
1
X X X
22E Hose Fitting, Brass
S25524
1
X X X
22G Flex Hose (Ref. Thermostat to Radiator)
T10642-263
1
X X X
22H Clamps
S10888-35
2
X X X
23A Case Side-Left
G3511
1
X X X
23B Thread Forming Screw (Cutting) (Not Shown)
S9225-68
3
X X X
24
Cover Seal (Codes 11121 & 11188)
S12934
1
X X •
24
Cover Seal (Codes 11275 & 11457)
S12934-1
1
• X X
