Lincoln Electric IM970 RANGER 305 D User Manual
Page 59
2A
Top Bezel
G3593
1
X X
2B
Self Tapping Screw (Not Shown)
S24738-1
4
X X
3A
Right Bezel
G3594-1
1
X X
3B
Self Tapping Screw (Not Shown)
S24738-1
2
X X
4A
Left Bezel
G3594-2
1
X X
4B
Self Tapping Screw (Not Shown)
S24738-1
2
X X
5
Switch, Push-Button
S13146-4
1
X X
6
Start Button
S13146-1
1
X X
7
Hour Meter-Miniature
S17475-3
1
X X
12
Knob
T10491-1
1
X X
13
“O” Ring (Not Shown)
T13483-7
2
X X
14
Connector & Lead Assembly (Includes)
M19685-4
1
X X
14A
Potentiometer (10K)
T10812-112
2
X X
14B
Potentiometer Spacer
S18280
2
X X
14C
Rotary Switch (Not Shown)
S16670-10
1
X X
15
Switch, Toggle, SPST (Idle Switch)
T10800-38
1
X X
15A Sealing Boot (Not Shown)
S22061-4
1
• X
16
Nameplate-Ranger
®
305D
G4577
1
X X
17
Switch, Toggle, DPDT
T10800-36
1
X X
17A Sealing Boot (Not Shown)
S22061-4
1
• X
18
Knob
T10491
2
X X
19
Front Door Nameplate
L11746-2
1
X X
20A Door Welded Assembly
L11185
1
X X
20B Rivet (Not Shown)
T12584-6
2
X X
21
Latch
S21033
1
X X
22A Catch Bracket
S24659
1
X X
22B Self Tapping Screw (Not Shown)
S8025-98
2
X X
23
Fuel Gauge
S17585-1
1
X X
24
Plug & Lead Asbly (Not Shown)
S18250-889
1
X X
25
Operation Decal
M19452-3
1
X X
26
Pilot Light
T13534-11
1
X X
27
Digital Weld Meter Kit, Includes: (27A thru 27E)
K2467-1
1
X X
27A
Meter Housing Asbly (L11160)
NSS
2
X X
27B
Meter Housing Seal
S24630
2
X X
27C
Meter Bezel
M19368
2
X X
27D
Lens (Not Shown)
T14807-9
2
X X
27E
#4-40 x .375 SS-PPNHS (Not Shown)
CF000389
4
X X
27F #6-32 HN (Not Shown)
CF000005
4
X X
27G Plain Washer (Not Shown)
S9262-3
4
X X
28
Toggle Switch
T10800-39
1
X X
28A Sealing Boot (Not Shown)
S22061-4
1
• X
29
Switch, Toggle, SPST
T10800-38
1
X X
29A Sealing Boot (Not Shown)
S22061-4
1
• X
04-12-2010
RANGER
®
305D
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-492-D.1
